Arista 7050SX3 Series Pricing, Features & Reviews
What is Arista 7050SX3 Series?
The Arista 7050X3 Series is a line of high-performance, fixed-configuration 10/25G and 100G Ethernet switches designed for cloud-scale data centers. As the demand for high-performance servers utilizing virtualization and containers with elevated bandwidth continues to surge, this series addresses this need with dense 25 and 100-G Ethernet switching capabilities strategically positioned in both the leaf and spine tiers of modern networks.
Designed for flexibility and performance, the switches offer wire-speed Layer 2 (L2) and Layer 3 (L3) features, combining extensive automation, programmability, low latency, and consistent features to meet the requirements of software-driven cloud networking. The series is available in various configuration options, each exemplifying high density and industry-leading power efficiency, with typical power consumption under 7W per 100GbE port. With flexible forwarding tables, low latency starting from 800 ns, and a fully shared packet buffer of up to 32MB for superior burst absorption, it excels in diverse network environments.
Why Choose Arista 7050SX3 LAN Switching Tool?
- The Lan Switching Tool enables efficient routing and forwarding at the network layer for enhanced scalability and performance.
- It allows multiple physical links to be combined into a single logical link for enhancing bandwidth and providing redundancy.
- It enhances network resilience by grouping multiple physical links into a single logical link and distributing traffic for improved performance and fault tolerance.
- With support for Link Layer Discovery Protocol (LLDP), the series enables the discovery and exchange of information between neighboring network devices.
- It dynamically maps private IP addresses to public addresses for efficient use of IP resources.
Benefits of Arista 7070SX3 Series
- The switching tool provides a standardized set of data and variables to facilitate the monitoring and management of network devices through a unified interface.
- It ensures rapid convergence and fault tolerance in network environments by providing per-VLAN spanning-tree instances.
- The series facilitates communication between the control and forwarding planes in software-defined networking (SDN) environments.
- It allows the duplication of network traffic from one port to another for analysis and monitoring purposes.
- It monitors and controls broadcast, multicast, or unicast traffic levels to prevent network storms and maintain stability.
Technical Specifications of Arista 7050SX3 LAN Switching Tool
- Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3by, IEEE 802.3x, IEEE 802.3z
- Form Factor (Hubs & Switches): Rack-mountable
- Jumbo Frame Support: 9216 bytes
- MAC Address Table Size: 288K entries
- Ports: 48
- Remote Management: CLI, RMON, RMON 2, SNMP 1, SNMP 2, SNMP 3, SSH-2, Telnet
- Routing Protocol: BGP, Bidirectional Forwarding Detection (BFD), ECMP, IGMP, IGMPv2, IGMPv3, IS-IS, Multiprotocol BGP, OSPF, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-2, URPF, Virtual ARP (VARP), VRRP
- Switching Type: 10 Gigabit Ethernet
- Performance: Latency: 800 ns, Packets per second: 1 Bpps, Throughput: 2.56 Tbps
- Operating System: Arista EOS
Arista 7050SX3 Series Pricing
Arista 7050X3 Series pricing details are available on request at techjockey.com.
Its price in India may vary based on factors like customization, additional features required, the number of users, and the deployment type. Please request a call back for subscription-related details and to avail offers on premium packages.
